Eaton GHG2640021R0001

Eaton GHG2640021R0001 by Eaton

Call for Price
  • Part Number: GHG2640021R0001
  • UPC:
  • Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
CEAG GHG2640021R0001 Explosionproof Safety Switch, 690 VAC, 80 A, 50 hp at 240 VAC/30 hp at 600 VAC, 1NO-1NC Contact Form, 6 Poles
Specifications
Details
Category Level 1:
Distribution Equipment & Accessories
Category Level 2:
Safety & Disconnect Switches
Category Level 3:
Hazardous Location Safety Switches
Amperage Rating:
80
80 A
Application:
Individual Motor Control Applications
Category Name:
Hazardous Location Safety Switches
Color:
Black
Contact Form:
1NO-1NC
Country:
USA
Dimensions:
10.67 in H x 10.67 in W x 11.61 in D
Enclosure Type:
NEMA 4X/IP66
Frequency Rating:
50/60
50/60 Hz
Horsepower:
50 hp at 240 VAC/30 hp at 600 VAC
Length:
0.0
Material:
Glass Fibre Reinforced Polyester
Number of Poles:
6
Standard/Approvals:
CSA C22.2 No. 14, cCSAus Certified|Class I, Division 2, Groups A, B, C, D, Class I, Zones 1 and 2, AEx de IIC, T6, Class II, Division 1, Groups E, F, G (CSA), Class II, Division 2, Groups F, G|ATEX Approved PTB, Ex de IIC, T6, Zones 1 and 2A, IP66, GOST-R
Temperature Rating:
-20 to 40
-20 to 40 deg C
Type:
Explosionproof
Unspsc:
39121309
Voltage Rating:
690
690 VAC
Volume:
0.0
Weight:
9.0
Additional Information
Manufactured By:
Eaton
